Community Wave
If you’re a contractor or installer connecting rooftop solar, battery or EV chargers, you play a vital role in our Virtual Power Plant. It’s known as Community Wave.
We’re here to help you make sense of Community Wave so you can share the right information with your customers:
- you'll find answers to questions your customers might ask; and
- the technical specifications to enable Smart Connect Solar and Battery.
What is Community Wave?
Community Wave is our very own Virtual Power Plant (VPP) which helps customers get more value out of their solar and battery energy systems.
It connects your system to the local network - and balances the supply and demand of electricity across the whole community.
This means fewer outages and more access to solar energy for everyone.
+ Community Wave Buyback Bonus rebates
+ Community Wave help and support
All solar and battery installations need to be Smart Connected
To keep the network stable, Community Wave connects to the customer's assets using a Secure Gateway Device (SGD).
This allows us to adjust solar energy generation at different times of the day. In return, eligible customers can access exclusive buyback rates for exporting excess energy back to the grid.
If your customer is adding a battery to their existing system, they must connect it to an inverter compatible with our SGD.
Why?
Monitors all energy sources
Connected to the network including rooftop solar, power stations and renewable energy farms.
Smooths rooftop solar energy
Due to its intermittent generation caused by weather. This drives uneven energy flow into the network.
Maintains network stability
By uniformly turning turn down solar generation when this is at risk.
Training requirements
To install Smart Connect Solar, you need to complete our new Solar Acreditation Australia course and get up to speed on our technical requirements.
complete a free micro accreditation through either the Solar Accreditation Australia (SAA) or
SwitchDin Academy.
As a part of your training, there is also a variety of supporting materials. Links to these resources will be provided through your training.
Once you have completed the registration process you can download the Stormcloud App on your mobile or tablet.
If further assistance is required during install, SwitchDin's technical support will be provide assistance:
Complete the free micro accreditation
So you're approved to install install solar and battery across the Horizon Power network.
Compatible inverters
For all solar and battery connections
Only Clean Energy Council (CEC) approved inverters and battery models, can be connected to our network.
For Basic EG connections (less than 30kVa)
A subset of CEC approved inverter models can be used. These are models currently compatible with the SGD (supplied by us). This list will continue to grow as more inverters become compatible.
See the compatible inverter list below.
| Model | Supported inverter sizes |
| Symo (Test) | SYMO 3.0-3-M |
| SYMO 3.7-3-M | |
| SYMO 4.5-3-M | |
| SYMO 5.0-3-M | |
| SYMO 6.0-3-M | |
| SYMO 7.0-3-M | |
| SYMO 8.2-3-M | |
| SYMO 10.0-3-M | |
| SYMO 12.5-3-M | |
| SYMO 15.0-3-M | |
| SYMO 17.5-3-M | |
| SYMO 20.0-3-M | |
|
Primo (SnapInverter) |
PRIMO 3.0-1 |
| PRIMO 3.5-1 | |
| PRIMO 3.6-1 | |
| PRIMO 4.0-1 | |
| PRIMO 4.6-1 | |
| PRIMO 5.0-1 | |
| PRIMO 5.0-1AUS | |
| PRIMO 5.0-1 SC | |
| PRIMO 6.0-1 | |
| PRIMO 8.2-1 | |
|
Eco (SnapInverter) |
FRONIUS ECO 25.0-3-S |
| FRONIUS ECO 27.0-3-S | |
| Symo GEN24(+) |
SYMO GEN24 3.0 SC (AS4777-2 2020) |
| SYMO GEN24 3.0 Plus SC (AS4777-2 2020) | |
| SYMO GEN24 3.0 (AS4777-2 2020) | |
| SYMO GEN24 3.0 Plus (AS4777-2 2020) | |
| SYMO GEN24 4.0 SC (AS4777-2 2020) | |
| SYMO GEN24 4.0 Plus SC (AS4777-2 2020) | |
| SYMO GEN24 4.0 (AS4777-2 2020) | |
| SYMO GEN24 4.0 Plus (AS4777-2 2020) | |
| SYMO GEN24 5.0 SC (AS4777-2 2020) | |
| SYMO GEN24 5.0 Plus SC (AS4777-2 2020) | |
| SYMO GEN24 5.0 (AS4777-2 2020) | |
| SYMO GEN24 5.0 Plus (AS4777-2 2020) | |
| SYMO GEN24 6.0 SC (AS4777-2 2020) | |
| SYMO GEN24 6.0 Plus SC (AS4777-2 2020) | |
| SYMO GEN24 6.0 (AS4777-2 2020) | |
| SYMO GEN24 6.0 Plus (AS4777-2 2020) | |
| SYMO GEN24 8.0 SC (AS4777-2 2020) | |
| SYMO GEN24 8.0 Plus SC (AS4777-2 2020) | |
| SYMO GEN24 8.0 (AS4777-2 2020) | |
| SYMO GEN24 8.0 Plus (AS4777-2 2020) | |
| SYMO GEN24 10.0 SC (AS4777-2 2020) | |
| SYMO GEN24 10.0 Plus SC (AS4777-2 2020) | |
| SYMO GEN24 10.0 (AS4777-2 2020) | |
| SYMO GEN24 10.0 Plus (AS4777-2 2020) | |
| SYMO GEN24 12.0 SC (AS4777-2 2020) | |
| SYMO GEN24 12.0 Plus SC (AS4777-2 2020) | |
| Primo GEN24(+) | PRIMO GEN24 10.0 (AS4777-2 2020) |
| PRIMO GEN24 10.0 Plus (AS4777-2 2020) | |
| PRIMO GEN24 3.0 (AS4777-2 2020) | |
| PRIMO GEN24 3.0 Plus (AS4777-2 2020) | |
| PRIMO GEN24 3.6 (AS4777-2 2020) | |
| PRIMO GEN24 3.6 Plus (AS4777-2 2020) | |
| PRIMO GEN24 4.0 (AS4777-2 2020) | |
| PRIMO GEN24 4.0 Plus (AS4777-2 2020) | |
| PRIMO GEN24 4.6 (AS4777-2 2020) | |
| PRIMO GEN24 4.6 Plus (AS4777-2 2020) | |
| PRIMO GEN24 5.0 (AS4777-2 2020) | |
| PRIMO GEN24 5.0 Plus (AS4777-2 2020) | |
| PRIMO GEN24 6.0 (AS4777-2 2020) | |
| PRIMO GEN24 6.0 Plus (AS4777-2 2020) | |
| PRIMO GEN24 8.0 (AS4777-2 2020) | |
| PRIMO GEN24 8.0 Plus (AS4777-2 2020) | |
| Verto | Verto 15.0 (AS4777-2 2020) |
| Verto 17.5 (AS4777-2 2020) | |
| Verto 20.0 (AS4777-2 2020) | |
| Verto 24.0 (AS4777-2 2020) | |
| Verto 25.0 (AS4777-2 2020) | |
| Verto 25.0 (AS4777-2 2020) | |
| Verto 27.0 (AS4777-2 2020) | |
| Verto 30.0 (AS4777-2 2020) |
| Model | Supported inverter sizes |
| ET Series | GW5KL-ET |
| GW6KL-ET | |
| GW8KL-ET | |
| GW10KL-ET | |
| GW15K-ET | |
| GW20K-ET | |
| GW25K-ET | |
| GW29.9K-ET | |
| EH Series | GW3600-EH |
| GW3600N-EH | |
| GW5000-EH | |
| GW5000N-EH | |
| GW6000-EH | |
| GW6000N-EH |
| Model | Supported inverter sizes |
| MID TL-XH Series | MID 10KTL3-XH |
| MID 11KTL3-XH | |
| MID 12KTL3-XH | |
| MID 13KTL3-XH | |
| MID 15KTL3-XH | |
| MID 17KTL3-XH | |
| MID 20KTL3-XH | |
| MID 25KTL3-XH | |
| MID 30KTL3-XH | |
| MIN TL-X Series | MIN 2500TL-X |
| MIN 2500TL-XH2 | |
| MIN 3000TL-X | |
| MIN 3000TL-XH2 | |
| MIN 3600TL-X | |
| MIN 3600TL-XH2 | |
| MIN 4200TL-X | |
| MIN 4200TL-XH2 | |
| MIN 4600TL-X | |
| MIN 4600TL-XH2 | |
| MIN 5000TL-X | |
| MIN 5000TL-XH2 | |
| MIN 6000TL-X | |
| MIN 6000TL-XH2 | |
| MOD TL3-X Series | MOD 3000TL3-XA |
| MOD 3000TL3-XH | |
| MOD 4000TL3-XA | |
| MOD 4000TL3-XH | |
| MOD 5000TL3-XA | |
| MOD 5000TL3-XH | |
| MOD 6000TL3-XA | |
| MOD 6000TL3-XH | |
| MOD 7000TL3-XA | |
| MOD 7000TL3-XH | |
| MOD 8000TL3-XA | |
| MOD 8000TL3-XH | |
| MOD 9000TL3-XA | |
| MOD 9000TL3-XH | |
| MOD 10KTL3-X-A | |
| MOD 10KTL3-XH | |
| SPA TL Series | SPA 3600TL-AUB |
| SPA 4000TL-AUB | |
| SPA 4600TL-AUB | |
| SPA 5000TL-AUB | |
| SPA 6000TL-AUB | |
| SPH TL Series | SPH 3600TL-HU |
| SPH 3600TL-HUB | |
| SPH 4000TL-HU | |
| SPH 4000TL-HUB | |
| SPH 4600TL-HU | |
| SPH 4600TL-HUB | |
| SPH 5000TL-HU | |
| SPH 5000TL-HUB | |
| SPH 6000TL-HU | |
| SPH 6000TL-HUB |
| Model | Supported inverter sizes |
| SigenStor EC 3.0 SP AU | |
| SigenStor EC 3.6 SP AU | |
| SigenStor EC 4.0 SP AU | |
| SigenStor EC 4.6 SP AU | |
| SigenStor EC 5.0 SP AU | |
| SigenStor EC 6.0 SP AU |
|
| SigenStor EC 8.0 SP AU |
|
| SigenStor EC 10.0 SP AU |
|
| SigenStor EC 12.0 SP AU |
|
| SigenStor EC 5.0 TP AU |
|
| SigenStor EC 6.0 TP AU |
|
| SigenStor EC 8.0 TP AU |
|
| SigenStor EC 10.0 TP AU |
|
| SigenStor EC 12.0 TP AU |
|
| SigenStor EC 15.0 TP AU |
|
| SigenStor EC 17.0 TP AU |
|
| SigenStor EC 20.0 TP AU |
|
| SigenStor EC 25.0 TP AU |
|
| SigenStor EC 30.0 TP AU |
| Model | Supported inverter sizes |
| Sunny Boy AV-41 | SB3.0-1AV-41 |
| SB4.0-1AV-41 | |
| SB5.0-1AV-41 | |
| SB6.0-1AV-41 | |
| Sunny Boy Smart Energy | SBSE3.6-50 |
| SBSE4.0-50 |
|
| SBSE5.0-50 |
|
| SBSE6.0-50 |
|
| Sunny Tripower AV-40 | STP3.0-3AV-40 |
| STP4.0-3AV-40 | |
| STP5.0-3AV-40 | |
| STP6.0-3AV-40 | |
| STP8.0-3AV-40 | |
| STP10.0-3AV-40 |
| Model | Supported inverter sizes |
| KTLM series |
SOFAR 3KTLM-G3 |
| SOFAR 3.6KTLM-G3 | |
| SOFAR 4KTLM-G3 | |
| SOFAR 4.6KTLM-G3 | |
| SOFAR 5KTLM-G3 | |
| SOFAR 5KTM-G3-A | |
| SOFAR 6KTLM-G3 | |
| SOFAR 7KTLM-G3 | |
| SOFAR 8KTLM-G3 | |
| SOFAR 9KTLM-G3 | |
| SOFAR 10KTLM-G3 | |
| KTLX series |
SOFAR 3.3KTLX-G3 |
| SOFAR 4.4KTLX-G3 | |
| SOFAR 5.5KTLX-G3 | |
| SOFAR 6.6KTLX-G3 | |
| SOFAR 8.8KTLX-G3 | |
| SOFAR 12KTLX-G3 | |
| SOFAR 15KTLX-G3 | |
| SOFAR 17KTLX-G3 | |
| SOFAR 20KTLX-G3 | |
| SOFAR 22KTLX-G3 | |
| SOFAR 24KTLX-G3 | |
| SOFAR 25KTLX-G3 | |
| SOFAR 30KTLX-G3 |
| Model | Supported inverter sizes |
| X1 Mini series | X1 MINI 0.6K-G4 |
| X1 MINI 0.7K-G4 | |
| X1 MINI 1.1K-G4 | |
| X1 MINI 1.5K-G4 | |
| X1 MINI 2.0K-G4 | |
| X1 MINI 2.5K-G4 | |
| X1 MINI 3.0K-G4 | |
| X1 MINI 3.3K-G4 | |
| X1 Boost |
X1 BOOST 2.5K-G4 |
| X1 BOOST 3K-G4 | |
| X1 BOOST 3.3K-G4 | |
| X1 BOOST 3.6K-G4 | |
| X1 BOOST 4.2K-G4 | |
| X1 BOOST 5K-G4 | |
| X1 BOOST 6K-G4 | |
| X3 Pro | X3 PRO 8K-G2 |
| X3 PRO 10K-G2 | |
| X3 PRO 12K-G2 | |
| X3 PRO 15K-G2 | |
| X3 PRO 17K-G2 | |
| X3 PRO 20K-G2 | |
| X3 PRO 25K-G2 | |
| X3 PRO 30K-G2 | |
| X1 Hybrid | X1 HYBRID 3.0-D |
| X1 HYBRID 3.7-D | |
| X1 HYBRID 5.0-D | |
| X1 HYBRID 6.0-D | |
| X1 HYBRID 7.5-D | |
| X3 Hybrid | X3 HYBRID 5.0-D |
| X3 HYBRID 6.0-D | |
| X3 HYBRID 8.0-D | |
| X3 HYBRID 10.0-D | |
| X3 HYBRID 12.0-D | |
| X3 HYBRID 15.0-D |
| Model | Supported inverter sizes |
| SG5.0RT (AS4777-2 2020) | |
| SG7.0RT (AS4777-2 2020) | |
| SG8.0RT (AS4777-2 2020) | |
| SG15RT (AS4777-2 2020) | |
| SG20RT (AS4777-2 2020) |
Inverter configuration update
All systems must be configured with Australia Region C settings in accordance with AS4777.2:2020.Horizon Power has been made aware of an issue with the connect and reconnect over-frequency setting in AS4777.2:2020 (Section 4.7 in our DER Technical Requirements). For new Basic and LV EG connections, this setting is required to be updated to 50.5Hz to comply with the new Technical Requirements.
Horizon Power is working with Standards Australia to have this updated in AS4777.2:2020. However, in the interim, a manual update to this setting is recommended to ensure inverters operating in our service area work correctly.
